Specification：

* Brand：Aleaivy

* Battery Cell Composition: Lithium Ion A+++++ cell

* Voltage: 36 Volt /48 Volt

* Capacity (amp hours) : 10Ah / 15Ah / 20Ah

* Power:0W-2000W

* OUR HOLDER Plug:5-PIN

*Energy:

360Wh(36V 10AH)/540Wh(36V 15AH)

480Wh(48V 10AH)/960Wh(48V   20AH)

*BMS: 30A(36V/48V 10Ah Battery)/40A(36V/48V 15Ah   20Ah Battery)

*Charge Temperature Range: -20°C-55°C/-4~131 ℉

*Chemical Composition: Lithium Iron Phosphate (LiFePO4)

*Discharge Temperature: -20~ 65°C/-4~149 ℉

*Maximum continuous discharge:

30A(36V/48V 10Ah  Battery)/40A(36V/48V 15Ah 20Ah Battery)

*Type: Lithium Battery

* Peak Discharge Current :75A(30A BMS) 120A(40A BMS)

* Continuous Discharge Current :

30A(36V/48V10Ah   Battery)/40A(36V/48V15Ah 20Ah Battery)

* Fit ebike: For 36V/48V 200W-2000W ebike Electric Bike

* Long life 1500+ deeply cycles,Quality Grade A+++++ cell, Riding time   longer than ordinary batteries.

* Built in BMS with short circuit , over-current , over-heat , over-charge , over-discharge protection.

About the Battery Lights

Press the“" button the lights will turn on.

Lights-1 Red 3 Green---100%

Lights-1 Red 2 Green---75%

Lights-1 Red 1 Green---50%

Lights-1 Red 0 Green---25%(you need to charge the battery at this time)

Package List:

* 1 x 36V/48V 10Ah 15Ah 20Ah Hailong Battery

* 1 x Battery Fix Plate /Frame mount With Discharging Line

* 1 x 42V 2A /54.6V 2A US Charger

* 1 x 30Amp/40Amp BMS

* 2 x Keys

* 1 x Male XT60 Connector

* 1 x Female XT60 Connector

* 3 x Screws(One spare)

Charging note: Please connect the charger to the power supply first, and then connect the charger to the battery
